2016 Ram 1500 towing capacity.

Published towing ratings for the 2016 Ram 1500 run from 4,170 - 10,640 lbs depending on engine, cab, axle ratio, box length, drivetrain, and equipment.

Find your exact towing capacity Run the 2016 lookup tool → Compare engine families View 2016 powertrain matrix → View full comparison chart Full model index →

Retrieved from official Ram 2016 towing guide publications. Citations available below.

2016 Ram 1500
2016 TOWING RANGE
4,170 - 10,640 LBS
PEAK PAYLOAD
1,890 LBS
MAX GCWR
15,950 LBS
POWERTRAIN

Towing Capacity by Engine

Your engine determines your base towing limit. Start here to see the 2016 ratings for your specific Ram 1500 setup.

Highest Capacity
5.7L V8 HEMI
Range: 5,030 - 10,640 lbs
Max rating 10,640 LBS
3.0L V6 EcoDiesel
Range: 7,540 - 9,210 lbs
Max rating 9,210 LBS
3.6L V6
Range: 4,170 - 7,610 lbs
Max rating 7,610 LBS
GUIDE POLICY COVERAGE
PARTIAL
Passenger / options / tongue fields stay blank when the guide omits them.
PUBLISHED LOAD INPUTS PASSENGER / OPTIONS / TONGUE
300 / N/A / N/A
N/A means the reviewed guide notes omit that field.
PAYLOAD METHOD SAE J2807
Payload = GVWR – Base Weight.
Payload = GVWR – Base Weight. · Estimated values · Rounded to nearest 10 lbs · pounds
SOURCE GUIDE REFERENCE
p.1
ram-1500-towing-guide.pdf
VIEW PARTIAL GUIDE NOTES
PARTIAL GUIDE POLICY

Ground rules behind every 2016 Ram 1500 towing number.

These are the source-backed guide notes Ram actually prints for the Ram 1500 family in 2016.

FIG. 2016 LOAD Published Assumptions

Load assumptions the guide explicitly prints

  • Passenger weight: 300 lbs counted for driver and passengers.
FIG. 2016 CALC Payload Formula

How Ram derives payload from curb weight

  • Formula: Payload = GVWR – Base Weight.
  • Values: Published as estimated (not guaranteed).
  • Units: pounds
  • Rounding: nearest 10 lbs.
FIG. 2016 STD Rating Standard

SAE J2807 guidance

  • Trailer Weight Rating and Tow Vehicle Trailering Weight are calculated as specified in SAE J2807.
FIG. 2016 WARN Warnings

Manufacturer safety warnings

  • Payload and Trailer Weight Rating are mutually exclusive.
  • GAWRs, GVWRs and GCWRs should never be exceeded.
FIG. 2016 NOTES Policy Notes

All published notes from the 2016 towing guide

  • Payload and Max Trailer Weights are ESTIMATED values. p.1
  • All weights are shown in pounds unless otherwise stated. p.1
  • Payload and Max Trailer Weight values are rounded to the nearest 10 lb. p.1
  • Payload = GVWR – Base Weight. p.1
  • Trailer Weight Rating and Tow Vehicle Trailering Weight are calculated as specified in SAE J2807. p.1
  • Passenger Weight = 300 lb. p.1
  • Options Weight is option content above 33 percent of sales volume. p.1
  • Trailer equipment weight = Class IV receiver hitch is 11.1 lb (if not already included in options weight). Trailer Hitch is 10 lb if TWR is less or equal to 5,000 lb and 65 lb if TWR is greater than 5,000 lb. p.1
  • Payload and Trailer Weight Rating are mutually exclusive. p.1
  • GAWRs, GVWRs and GCWRs should never be exceeded. p.1
  • The recommended tongue weight for a conventional hitch is 10 percent of the gross trailer weight. The maximum tongue weight for Class IV receiver hitch is limited to 1100 lb. p.1
  • Weight Distributing Hitch is recommended for trailers over 5,000 lb. p.1
  • Quad Cab and Crew Cab models with Off Road Tire (s/c TXN), All Terrain Tire (s/c TWG) or Steel Wheel (s/c WFP) have 6800 lb GVWR. p.1
  • All models with 22 inch Tires (s/c TY4) have 6200 lb GVWR. p.1
  • Big Horn and Lone Star packages equipped with the 3.0L V6 EcoDiesel Engine and a 3.92 axle ratio have 13,750 lb. GCWR. p.1
NOTES: This strip shows only the guide-wide assumptions, warnings, standards, and availability limits Ram explicitly prints for this family. Missing fields stay blank instead of being inferred.
Technical Audit

Data sources

These citations show the Ram guide pages used to build the 2016 overview.

Show source pages for the 2016 guide
DOC_ID: ram-1500 DOCUMENT BASIS

ram-1500-towing-guide

Audit Scope PAGES: 1-5
PDF Creation Date 2015-05-25
