Lookup Tool Ford F-150
Find your exact F-150 towing row.
Default view shows all 2026 guide rows. Use filters to narrow by engine, cab, drivetrain, axle ratio, GCWR, and wheelbase.
Towing Capacity Chart
Matching configurations
Default view · 131 2026 guide rows
| Year | Engine | Axle | GCWR | Cab | Drive | Wheelbase | Tow Type | Result | Requirements |
|---|---|---|---|---|---|---|---|---|---|
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 19,400 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 13,500 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 19,300 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 13,300 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 19,400 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 13,100 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 18,100 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 12,800 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 12,800 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 17,900 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 12,700 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 12,700 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 18,400 lbs | SuperCrew | 4x2 | 157.2 in | Conventional | 12,400 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.55 | 18,400 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 12,300 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 17,700 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 12,300 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 18,100 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 11,700 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 11,600 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 11,500 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.55 | 17,100 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 11,100 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 17,100 lbs | SuperCrew | 4x2 | 157.2 in | Conventional | 11,100 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,500 lbs | Regular Cab | 4x4 | 141.5 in | Conventional | 11,000 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,500 lbs | Regular Cab | 4x4 | 141.5 in | Conventional | 11,000 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,200 lbs | Regular Cab | 4x2 | 141.5 in | Conventional | 10,900 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,200 lbs | Regular Cab | 4x2 | 141.5 in | Conventional | 10,900 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,300 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 10,900 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,300 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 10,900 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,800 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 10,900 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,800 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 10,900 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,200 lbs | Regular Cab | 4x2 | 141.5 in | 5th-Wheel / Gooseneck | 10,800 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,200 lbs | Regular Cab | 4x2 | 141.5 in | 5th-Wheel / Gooseneck | 10,800 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 17,100 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,800 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 17,100 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 10,800 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,600 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 10,700 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,600 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 10,700 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 17,700 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 10,700 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,500 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 10,600 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,500 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 10,600 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.73 | 17,100 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,600 lbs | Tremor Trim Series |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,800 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,500 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,800 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,900 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 10,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,600 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 10,400 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,700 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 10,400 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 19,300 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 10,300 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,700 lbs | Regular Cab | 4x4 | 141.5 in | Conventional | 10,300 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,500 lbs | Regular Cab | 4x4 | 141.5 in | 5th-Wheel / Gooseneck | 10,200 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,500 lbs | Regular Cab | 4x4 | 141.5 in | 5th-Wheel / Gooseneck | 10,200 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,300 lbs | Regular Cab | 4x2 | 141.5 in | Conventional | 10,200 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,600 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 10,200 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 17,900 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 10,200 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,800 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,200 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,300 lbs | Regular Cab | 4x2 | 141.5 in | 5th-Wheel / Gooseneck | 10,100 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,800 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 10,100 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,800 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,000 lbs | Tremor Trim Series |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 10,000 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 10,000 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | F-150 Lightning | 9.61 (Fixed) | 17,300 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 10,000 lbs | Max Trailer Tow Package |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,700 lbs | Regular Cab | 4x4 | 141.5 in | 5th-Wheel / Gooseneck | 9,900 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,900 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 9,800 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 17,700 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 9,800 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | F-150 Lightning | 9.61 (Fixed) | 16,800 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 9,700 lbs | Max Trailer Tow Package + 20 in All-Terrain tires |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.15 | 14,800 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 9,600 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 9,600 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,800 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 9,600 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,900 lbs | Regular Cab | 4x4 | 141.5 in | 5th-Wheel / Gooseneck | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,900 lbs | Regular Cab | 4x4 | 141.5 in | Conventional | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.15 | 14,800 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,900 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.15 | 14,800 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 9,500 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,700 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,500 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 14,600 lbs | Regular Cab | 4x4 | 122.8 in | Conventional | 9,400 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,900 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 9,400 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.15 | 14,800 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,400 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,400 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,800 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 9,300 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 17,100 lbs | SuperCrew | 4x2 | 157.2 in | 5th-Wheel / Gooseneck | 9,200 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 18,400 lbs | SuperCrew | 4x2 | 157.2 in | 5th-Wheel / Gooseneck | 9,200 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 9,200 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 9,100 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 9,100 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.31 | 14,800 lbs | SuperCrew | 4x4 | 157.2 in | Conventional | 9,100 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 19,400 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 9,000 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.55 | 17,100 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,000 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.55 | 18,400 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 9,000 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 13,900 lbs | Regular Cab | 4x2 | 122.8 in | Conventional | 9,000 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 19,400 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,700 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 13,900 lbs | Regular Cab | 4x2 | 122.8 in | 5th-Wheel / Gooseneck | 8,700 lbs | |
| 2026 | 5.2L Supercharged V8 | 4.10 | 15,300 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 8,700 lbs | Raptor R only |
| 2026 | F-150 Lightning | 9.61 (Fixed) | 15,900 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 8,700 lbs | Platinum model |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,300 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 8,600 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,300 lbs | Regular Cab | 4x2 | 141.5 in | Conventional | 8,400 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,300 lbs | Regular Cab | 4x2 | 141.5 in | 5th-Wheel / Gooseneck | 8,300 lbs | |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 14,600 lbs | Regular Cab | 4x4 | 122.8 in | 5th-Wheel / Gooseneck | 8,300 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | Regular Cab | 4x4 | 141.5 in | Conventional | 8,200 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 8,200 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 8,200 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,600 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,200 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,600 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,200 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 17,700 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,200 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,800 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 8,200 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,800 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 8,200 lbs | |
| 2026 | 3.5L EcoBoost V6 High Output (3.5L GTDI V6 H. O.) | 4.10 | 14,600 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 8,200 lbs | Raptor only |
| 2026 | 3.5L EcoBoost V6 High Output (3.5L GTDI V6 H. O.) | 4.10 | 14,650 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 8,200 lbs | Raptor only |
| 2026 | 5.0L Ti-VCT V8 (5.0L 4-Valve V8) | 3.73 | 15,800 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,200 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tremor Trim Series |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | Regular Cab | 4x4 | 141.5 in | 5th-Wheel / Gooseneck | 8,100 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,500 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 8,100 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,500 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 8,100 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 8,000 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,500 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 8,000 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,300 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 8,000 lbs | |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.31 | 16,800 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,000 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.55 | 16,800 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,000 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 3.5L EcoBoost V6 (3.5L GTDI V6) | 3.73 | 17,100 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 8,000 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tremor Trim Series |
| 2026 | F-150 Lightning | 9.61 (Fixed) | 15,000 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 7,700 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,800 lbs | SuperCrew | 4x2 | 145.4 in | Conventional | 7,600 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,700 lbs | Regular Cab | 4x4 | 141.5 in | Conventional | 7,500 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,700 lbs | SuperCab | 4x2 | 145.4 in | Conventional | 7,500 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.55 | 13,000 lbs | SuperCrew | 4x4 | 145.4 in | Conventional | 7,500 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,300 lbs | Regular Cab | 4x2 | 141.5 in | Conventional | 7,400 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,700 lbs | Regular Cab | 4x4 | 141.5 in | 5th-Wheel / Gooseneck | 7,400 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,800 lbs | SuperCab | 4x4 | 145.4 in | Conventional | 7,400 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,300 lbs | Regular Cab | 4x2 | 141.5 in | 5th-Wheel / Gooseneck | 7,300 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,800 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 7,300 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | SuperCab | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 7,300 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,700 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 7,200 lbs | |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | SuperCab | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 7,200 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 17,100 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 7,200 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 7,200 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.15/3.55 | 12,800 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 7,100 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,400 lbs | SuperCrew | 4x2 | 145.4 in | 5th-Wheel / Gooseneck | 7,100 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 17,100 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 7,100 lbs | |
| 2026 | 3.5L PowerBoost Hybrid V6 (3.5L Hybrid V6) | 3.73 | 18,400 lbs | SuperCrew | 4x4 | 157.2 in | 5th-Wheel / Gooseneck | 7,100 lbs | Tow/Haul Package (53T) and optional Max Tow Axle |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.55 | 13,000 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 7,000 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
| 2026 | 2.7L EcoBoost V6 (2.7L GTDI V6) | 3.73 | 13,500 lbs | SuperCrew | 4x4 | 145.4 in | 5th-Wheel / Gooseneck | 7,000 lbs | Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model |
