2020 GMC Canyon Towing Capacity

Compare the ratings published for this model year, then match engine, cab, bed, drivetrain, axle ratio, and listed equipment to the truck.

View full comparison chart Review every configuration and published tow type → Browse Canyon years Return to the available model years →

11 configuration groups · 11 published rating outcomes

Published Max
7,700 LBS
Rating Groups
11
Equipment Checks
5
ENGINE GROUPS

Published Ratings by Engine

Your engine determines your base towing limit. Start here to see the 2020 ratings for your specific Canyon configuration.

Equipment-dependent ratings remain labeled until the listed truck details are confirmed.

2.8L Duramax Turbo Diesel 3 configuration groups
Range: 7,550–7,700 lbs
Published max 7,700 LBS
3.6L V6 5 configuration groups
Range: 7,000–7,000 lbs
Published max 7,000 LBS
2.5L I4 3 configuration groups
Range: 3,500–3,500 lbs
Published max 3,500 LBS
2020 Canyon towing chart
Engine group

2.8L Duramax Turbo Diesel

7,550–7,700 lbs

Towing Capacity Chart

2.8L Duramax Turbo Diesel configurations

3 groups 3 exact 7,550 to 7,700 lbs published
Crew Cab / Long Bed / 4WD 2.8L Duramax Turbo Diesel 3.42
Conventional: 7,550 lbs
12,700 lbs
No additional row condition listed p.21 Exact
Crew Cab / Short Bed / 2WD 2.8L Duramax Turbo Diesel 3.42
Conventional: 7,700 lbs
12,700 lbs
No additional row condition listed p.21 Exact
Crew Cab / Short Bed / 4WD 2.8L Duramax Turbo Diesel 3.42
Conventional: 7,600 lbs
12,700 lbs
No additional row condition listed p.21 Exact
Engine group

3.6L V6

7,000–7,000 lbs

Towing Capacity Chart

3.6L V6 configurations

5 groups 0 exact 5 equipment-conditioned 7,000 to 7,000 lbs published
Crew Cab / Long Bed / 4WD 3.6L V6 3.42
Conventional: 7,000 lbs
12,000 lbs
Requires available Trailering Package. p.21 Equipment check
Crew Cab / Short Bed / 2WD 3.6L V6 3.42
Conventional: 7,000 lbs
12,000 lbs
Requires available Trailering Package. p.21 Equipment check
Crew Cab / Short Bed / 4WD 3.6L V6 3.42
Conventional: 7,000 lbs
12,000 lbs
Requires available Trailering Package. p.21 Equipment check
Extended Cab / 2WD 3.6L V6 3.42
Conventional: 7,000 lbs
12,000 lbs
Requires available Trailering Package. p.21 Equipment check
Extended Cab / 4WD 3.6L V6 3.42
Conventional: 7,000 lbs
12,000 lbs
Requires available Trailering Package. p.21 Equipment check
Engine group

2.5L I4

3,500–3,500 lbs

Towing Capacity Chart

2.5L I4 configurations

3 groups 3 exact 3,500 to 3,500 lbs published
Crew Cab / Short Bed / 2WD/4WD 2.5L I4 4.10
Conventional: 3,500 lbs
8,500 lbs
No additional row condition listed p.21 Exact
Extended Cab / 2WD 2.5L I4 4.10
Conventional: 3,500 lbs
8,500 lbs
No additional row condition listed p.21 Exact
Extended Cab / 4WD 2.5L I4 4.10
Conventional: 3,500 lbs
8,500 lbs
No additional row condition listed p.21 Exact
Ratings

Tow types stay separate

Conventional, fifth-wheel, and gooseneck values are shown as distinct outcomes when GMC publishes more than one for a configuration.

Truck check

Equipment conditions stay visible

A condition attached to a rating remains part of the answer. It is not treated as an optional note.

Guide

Use the matching owner manual

Vehicle-wide towing guidance is not inferred from another GMC model or model year. Confirm it in the manual for this truck.

Technical Audit

Data sources

These citations identify the GMC trailering-guide pages used for the 2020 Canyon chart ratings.

Show source pages for the 2020 guide
DOC_ID: 2020-GMC DOCUMENT BASIS

2020-GMC-Trailering-Guide

Audit Scope PAGES: 21
