2026 Ford F-150 towing capacity chart

7 engines · Conventional, 5th-Wheel / Gooseneck · 2026 Ford F-150 Towing Guide, Ford RV & Trailer Towing Guide 2026

Open 2026 lookup Narrow to your exact truck

2026 Ford F-150 towing capacity chart

Engine Chart

2.7L EcoBoost V6

Ford chart label: 2.7L GTDI V6

7,000 – 8,400 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.15/3.55	4x2	141.5 in	12,300 lbs	7,400 lbs
3.15/3.55	4x4	141.5 in	12,700 lbs	7,500 lbs
3.73	4x2	141.5 in	13,300 lbs	8,400 lbs
3.73	4x4	141.5 in	13,400 lbs	8,200 lbs
SuperCab
3.15/3.55	4x2	145.4 in	12,700 lbs	7,500 lbs
3.15/3.55	4x4	145.4 in	12,800 lbs	7,400 lbs
3.73	4x2	145.4 in	13,400 lbs	8,200 lbs
3.73	4x4	145.4 in	13,400 lbs	8,000 lbs
SuperCrew
3.15/3.55	4x2	145.4 in	12,800 lbs	7,600 lbs
3.55	4x4	145.4 in	13,000 lbs	7,500 lbs
3.73	4x2	145.4 in	13,400 lbs	8,200 lbs
3.73	4x4	145.4 in	13,500 lbs	8,000 lbs

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.15/3.55	4x2	141.5 in	12,300 lbs	7,300 lbs
3.15/3.55	4x4	141.5 in	12,700 lbs	7,400 lbs
3.73	4x2	141.5 in	13,300 lbs	8,300 lbs
3.73	4x4	141.5 in	13,400 lbs	8,100 lbs
SuperCab
3.15/3.55	4x2	145.4 in	12,700 lbs	7,200 lbs
3.15/3.55	4x4	145.4 in	12,800 lbs	7,300 lbs
3.73	4x2	145.4 in	13,400 lbs	7,200 lbs
3.73	4x4	145.4 in	13,400 lbs	7,300 lbs
SuperCrew
3.15/3.55	4x2	145.4 in	12,800 lbs	7,100 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.55	4x4	145.4 in	13,000 lbs	7,000 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.73	4x2	145.4 in	13,400 lbs	7,100 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.73	4x4	145.4 in	13,500 lbs	7,000 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model

Engine Chart

3.5L EcoBoost V6

Ford chart label: 3.5L GTDI V6

8,000 – 13,500 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.31	4x2	141.5 in	16,200 lbs	10,900 lbs
3.31	4x4	141.5 in	16,500 lbs	11,000 lbs
3.55	4x2	141.5 in	16,200 lbs	10,900 lbs
3.55	4x4	141.5 in	16,500 lbs	11,000 lbs
SuperCab
3.31	4x2	145.4 in	16,300 lbs	10,900 lbs
3.31	4x4	145.4 in	16,600 lbs	10,700 lbs
3.55	4x2	145.4 in	16,300 lbs	10,900 lbs
3.55	4x4	145.4 in	16,600 lbs	10,700 lbs
3.55	4x4	145.4 in	17,700 lbs	10,700 lbs
SuperCrew
3.31	4x2	145.4 in	16,500 lbs	10,600 lbs
3.31	4x4	145.4 in	16,800 lbs	10,500 lbs
3.31	4x4	157.2 in	16,800 lbs	10,900 lbs
3.55	4x2	145.4 in	16,500 lbs	10,600 lbs
3.55	4x2	145.4 in	19,300 lbs	13,300 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.55	4x4	145.4 in	16,800 lbs	10,500 lbs
3.55	4x4	145.4 in	19,400 lbs	13,100 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.55	4x4	157.2 in	16,800 lbs	10,900 lbs
3.55	4x4	157.2 in	19,400 lbs	13,500 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	17,100 lbs	10,600 lbs	Tremor Trim Series

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

Regular Cab
3.31	4x2	141.5 in	16,200 lbs	10,800 lbs
3.31	4x4	141.5 in	16,500 lbs	10,200 lbs
3.55	4x2	141.5 in	16,200 lbs	10,800 lbs
3.55	4x4	141.5 in	16,500 lbs	10,200 lbs
SuperCab
3.31	4x2	145.4 in	16,300 lbs	8,000 lbs
3.31	4x4	145.4 in	16,600 lbs	8,200 lbs
3.55	4x2	145.4 in	16,300 lbs	8,600 lbs
3.55	4x4	145.4 in	16,600 lbs	8,200 lbs
3.55	4x4	145.4 in	17,700 lbs	8,200 lbs
SuperCrew
3.31	4x2	145.4 in	16,500 lbs	8,100 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.31	4x4	145.4 in	16,800 lbs	8,000 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.31	4x4	157.2 in	16,800 lbs	8,200 lbs
3.55	4x2	145.4 in	16,500 lbs	8,100 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.55	4x2	145.4 in	19,300 lbs	10,300 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle
3.55	4x4	145.4 in	16,800 lbs	8,000 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.55	4x4	145.4 in	19,400 lbs	8,700 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle
3.55	4x4	157.2 in	16,800 lbs	8,200 lbs
3.55	4x4	157.2 in	19,400 lbs	9,000 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	17,100 lbs	8,000 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tremor Trim Series

Engine Chart

3.5L EcoBoost V6 High Output

Ford chart label: 3.5L GTDI V6 H. O.

8,200 – 8,200 lbs

Towing Capacity Chart

Conventional towing

SuperCrew
4.10	4x4	145.4 in	14,600 lbs	8,200 lbs	Raptor only
4.10	4x4	145.4 in	14,650 lbs	8,200 lbs	Raptor only

Engine Chart

3.5L PowerBoost Hybrid V6

Ford chart label: 3.5L Hybrid V6

7,100 – 12,400 lbs Engine page →

Towing Capacity Chart

Conventional towing

SuperCrew
3.55	4x2	145.4 in	17,100 lbs	11,100 lbs
3.55	4x2	145.4 in	18,400 lbs	12,300 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x2	157.2 in	17,100 lbs	11,100 lbs
3.73	4x2	157.2 in	18,400 lbs	12,400 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	17,100 lbs	10,800 lbs
3.73	4x4	145.4 in	18,400 lbs	11,600 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	157.2 in	17,100 lbs	10,800 lbs
3.73	4x4	157.2 in	18,400 lbs	11,500 lbs	Tow/Haul Package (53T) and optional Max Tow Axle

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

SuperCrew
3.55	4x2	145.4 in	17,100 lbs	9,000 lbs
3.55	4x2	145.4 in	18,400 lbs	9,000 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x2	157.2 in	17,100 lbs	9,200 lbs
3.73	4x2	157.2 in	18,400 lbs	9,200 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	17,100 lbs	7,200 lbs
3.73	4x4	145.4 in	18,400 lbs	7,200 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	157.2 in	17,100 lbs	7,100 lbs
3.73	4x4	157.2 in	18,400 lbs	7,100 lbs	Tow/Haul Package (53T) and optional Max Tow Axle

Engine Chart

5.0L Ti-VCT V8

Ford chart label: 5.0L 4-Valve V8

8,200 – 12,800 lbs Engine page →

Towing Capacity Chart

Conventional towing

SuperCab
3.15	4x2	145.4 in	14,800 lbs	9,600 lbs
3.31	4x2	145.4 in	14,800 lbs	9,600 lbs
3.31	4x4	145.4 in	14,900 lbs	9,500 lbs
3.73	4x2	145.4 in	15,600 lbs	10,400 lbs
3.73	4x2	145.4 in	17,900 lbs	12,700 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	15,900 lbs	10,500 lbs
3.73	4x4	145.4 in	17,700 lbs	12,300 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
SuperCrew
3.15	4x2	145.4 in	14,800 lbs	9,500 lbs
3.31	4x2	145.4 in	14,800 lbs	9,500 lbs
3.31	4x4	145.4 in	14,800 lbs	9,200 lbs
3.31	4x4	157.2 in	14,800 lbs	9,100 lbs
3.73	4x2	145.4 in	15,700 lbs	10,400 lbs
3.73	4x2	145.4 in	18,100 lbs	12,800 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	15,800 lbs	10,000 lbs	Tremor Trim Series
3.73	4x4	145.4 in	15,800 lbs	10,200 lbs
3.73	4x4	145.4 in	18,400 lbs	12,800 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	157.2 in	15,800 lbs	10,100 lbs
3.73	4x4	157.2 in	18,400 lbs	12,700 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
Regular Cab
3.31	4x4	141.5 in	14,900 lbs	9,500 lbs
3.73	4x2	122.8 in	13,900 lbs	9,000 lbs
3.73	4x2	141.5 in	15,300 lbs	10,200 lbs
3.73	4x4	122.8 in	14,600 lbs	9,400 lbs
3.73	4x4	141.5 in	15,700 lbs	10,300 lbs

Towing Capacity Chart

5th-Wheel / Gooseneck Towing

SuperCab
3.15	4x2	145.4 in	14,800 lbs	9,500 lbs
3.31	4x2	145.4 in	14,800 lbs	9,500 lbs
3.31	4x4	145.4 in	14,900 lbs	9,400 lbs
3.73	4x2	145.4 in	15,600 lbs	10,200 lbs
3.73	4x2	145.4 in	17,900 lbs	10,200 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	15,900 lbs	9,800 lbs
3.73	4x4	145.4 in	17,700 lbs	9,800 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
SuperCrew
3.15	4x2	145.4 in	14,800 lbs	9,400 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.31	4x2	145.4 in	14,800 lbs	9,400 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.31	4x4	145.4 in	14,800 lbs	9,100 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.31	4x4	157.2 in	14,800 lbs	9,100 lbs
3.73	4x2	145.4 in	15,700 lbs	9,500 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.73	4x2	145.4 in	18,100 lbs	11,700 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	145.4 in	15,800 lbs	8,200 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tremor Trim Series
3.73	4x4	145.4 in	15,800 lbs	9,300 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.73	4x4	145.4 in	18,400 lbs	10,000 lbs	Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tow/Haul Package (53T) and optional Max Tow Axle
3.73	4x4	157.2 in	15,800 lbs	9,600 lbs
3.73	4x4	157.2 in	18,400 lbs	10,000 lbs	Tow/Haul Package (53T) and optional Max Tow Axle
Regular Cab
3.31	4x4	141.5 in	14,900 lbs	9,500 lbs
3.73	4x2	122.8 in	13,900 lbs	8,700 lbs
3.73	4x2	141.5 in	15,300 lbs	10,100 lbs
3.73	4x4	122.8 in	14,600 lbs	8,300 lbs
3.73	4x4	141.5 in	15,700 lbs	9,900 lbs

Engine Chart

5.2L Supercharged V8

8,700 – 8,700 lbs

Towing Capacity Chart

Conventional towing

SuperCrew
4.10	4x4	145.4 in	15,300 lbs	8,700 lbs	Raptor R only

Engine Chart

F-150 Lightning

Ford chart label: Electric (F-150 Lightning)

7,700 – 10,000 lbs

Towing Capacity Chart

Conventional towing

SuperCrew
9.61 (Fixed)	4x4	145.4 in	15,000 lbs	7,700 lbs
9.61 (Fixed)	4x4	145.4 in	15,900 lbs	8,700 lbs	Platinum model
9.61 (Fixed)	4x4	145.4 in	16,800 lbs	9,700 lbs	Max Trailer Tow Package + 20 in All-Terrain tires
9.61 (Fixed)	4x4	145.4 in	17,300 lbs	10,000 lbs	Max Trailer Tow Package

PHYSICAL LIMITS MAX HITCH

13,500 LBS

DOCUMENT RULES ALTITUDE

-2% / 1K FT

TOWING LAWS FRONTAL AREA

55-75 SQ FT

SAFETY BASELINE EQUIPMENT

4 RULES

Package matrix below

VIEW ALL POLICY RULES

FIG. 2026 LOAD Load + Altitude

Base loading guidance from Ford

Conventional: 10% tongue weight of total loaded trailer weight.
5th-wheel: 15% king pin weight of total loaded trailer weight.
High altitude: reduce gross combined weight by 2% per 1,000 ft of elevation.

FIG. 2026 HITCH Hitch Capacities

Receiver and bumper ratings vary by model scope

F-150 Pickup Hitch Receiver F-150 pickup non-Raptor Weight-carrying 5,000 / 500 lbs; weight-distributing 13,500 / 1,400 lbs.
F-150 Lightning Hitch Receiver F-150 Lightning Weight-carrying 5,000 / 500 lbs; weight-distributing 10,000 / 1,000 lbs.

FIG. 2026 FRONTAL Frontal Area

Frontal-area allowances are year and setup specific

Conventional towing

55 sq ft

F-150 pickup · N/A to 7,700 lbs 55 sq. ft. for vehicles with Trailer Tow Rating of 7,700 lbs. or less
65 sq ft

F-150 pickup · 7,701 lbs and up 65 sq. ft. for vehicles with Trailer Tow Rating of 7,701 lbs. and greater
60 sq ft

F-150 Lightning · All eligible trailer weights 60 sq. ft. for F-150 Lightning trailer combinations

5th-Wheel / Gooseneck

75 sq ft

F-150 pickup · All eligible trailer weights 75 sq. ft. for all 5th-Wheel and Gooseneck applications

FIG. 2026 SAFETY-BS Universal Safety Baseline

Required equipment and threshold rules for the 2026 guide

Available Trailer Tow Packages

F-150 (53T) · Max Tow Axle (NOC) · Raptor (NOC)

Raptor receiver setup is standard. A 2" hitch receiver rated at 11,600 lbs. is standard. Max Tow Axle includes 2" reinforced receiver rated at 14,000 lbs.

Your New Vehicle Limited Warranty may be voided if you tow without them.

F-150 pickup Conventional towing above 5,000 lbs requires a weight-distribution system.
F-150 gas pickup Gas F-150 pickups above 11,600 lbs require Tow/Haul Package (53T) and optional Max Tow Axle.
F-150 hybrid pickup Hybrid F-150 pickups above 10,800 lbs require Tow/Haul Package (53T) and optional Max Tow Axle.
F-150 Lightning F-150 Lightning above 5,000 lbs requires Max Trailer Tow Package (53D).

Technical Audit

Data sources

These citations show the Ford guide pages used to build the 2026 towing capacity chart.

Show source pages for the 2026 chart

DOC_ID: 2026-For DOCUMENT BASIS

2026 Ford F-150 Towing Guide

Audit Scope PAGES: 4, 6

PDF Creation Date 2025-10-20

DOC_ID: ford-tow DOCUMENT BASIS

Ford RV & Trailer Towing Guide 2026

Audit Scope PAGES: 9, 15-19

PDF Creation Date 2025-10-20

Guide Revision Date 2025-12-19
