Year Chart

2022 Ford F-150 towing capacity chart

7 engines · Conventional, 5th Wheel · Ford RV & Trailer Towing Guide 2022

Open 2022 lookup Narrow to your exact truck
2022 Ford F-150 Blueprint
Published Range
5,000 - 14,000 lbs
Conventional Max
14,000 lbs
5th-Wheel Max
14,000 lbs
2022 Ford F-150 towing capacity chart
Engine Chart

2.7L EcoBoost V6

Ford chart label: 2.7L GTDI V6

7,500 – 10,100 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.55 4x2 122.8 in 12,200 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 141.5 in 12,300 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 122.8 in 12,600 lbs 7,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 141.5 in 12,700 lbs 7,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 122.8 in 13,200 lbs 8,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 13,300 lbs 8,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 14,900 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 122.8 in 13,400 lbs 8,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 13,400 lbs 8,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 15,100 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCab
3.55 4x2 145.4 in 12,700 lbs 7,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 164.1 in 12,700 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 12,800 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 13,400 lbs 8,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,000 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 15,100 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,300 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,400 lbs 10,100 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCrew
3.55 4x2 145.4 in 12,800 lbs 7,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 157.2 in 12,900 lbs 7,800 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 13,000 lbs 7,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,200 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 15,200 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,400 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,500 lbs 10,100 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Towing Capacity Chart

5th-wheel towing

Regular Cab
3.55 4x2 122.8 in 12,200 lbs 7,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 141.5 in 12,300 lbs 7,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 122.8 in 12,600 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 141.5 in 12,700 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 122.8 in 13,200 lbs 8,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 13,300 lbs 8,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 14,900 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 122.8 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 15,100 lbs 9,900 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCab
3.55 4x2 145.4 in 12,700 lbs 7,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 164.1 in 12,700 lbs 7,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 12,800 lbs 7,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 13,400 lbs 8,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,000 lbs 9,900 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 15,100 lbs 9,900 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,300 lbs 8,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,400 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCrew
3.55 4x2 145.4 in 12,800 lbs 7,700 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 157.2 in 12,900 lbs 7,800 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 13,000 lbs 7,600 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 13,400 lbs 8,100 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,200 lbs 9,900 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 13,400 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 15,200 lbs 10,000 lbs 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,400 lbs 8,000 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,500 lbs 10,000 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + 2.7L EcoBoost Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Engine Chart

3.3L Ti-VCT V6

Ford chart label: 3.3L PFDI V6

5,000 – 8,200 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.55 4x2 122.8 in 9,500 lbs 5,000 lbs No additional row-specific requirement shown
3.55 4x2 141.5 in 9,600 lbs 5,000 lbs No additional row-specific requirement shown
3.55 4x4 122.8 in 9,800 lbs 5,000 lbs No additional row-specific requirement shown
3.73 4x2 122.8 in 12,700 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 12,800 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 122.8 in 12,900 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 12,900 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCab
3.55 4x2 145.4 in 9,900 lbs 5,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Trailer Tow Package (53B) or Max Trailer Tow Package
3.73 4x2 145.4 in 13,000 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,200 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCrew
3.55 4x2 145.4 in 10,000 lbs 5,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Trailer Tow Package (53B) or Max Trailer Tow Package
3.73 4x2 145.4 in 13,000 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,400 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Towing Capacity Chart

5th-wheel towing

Regular Cab
3.55 4x2 122.8 in 9,500 lbs 5,000 lbs No additional row-specific requirement shown
3.55 4x2 141.5 in 9,600 lbs 5,000 lbs No additional row-specific requirement shown
3.55 4x4 122.8 in 9,800 lbs 5,000 lbs No additional row-specific requirement shown
3.73 4x2 122.8 in 12,700 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 12,800 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 122.8 in 12,900 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 12,900 lbs 8,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCab
3.55 4x2 145.4 in 9,900 lbs 5,000 lbs No additional row-specific requirement shown
3.73 4x2 145.4 in 13,000 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,200 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCrew
3.55 4x2 145.4 in 10,000 lbs 5,000 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model
3.73 4x2 145.4 in 13,000 lbs 8,000 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 13,400 lbs 8,200 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Engine Chart

3.5L EcoBoost V6

Ford chart label: 3.5L GTDI V6

9,000 – 14,000 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.31 4x2 141.5 in 16,200 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 141.5 in 16,500 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 141.5 in 16,200 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 141.5 in 18,000 lbs 13,000 lbs Max Trailer Tow Package
3.55 4x4 141.5 in 16,500 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 141.5 in 18,000 lbs 12,700 lbs Max Trailer Tow Package
3.73 4x2 141.5 in 18,500 lbs 13,300 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 141.5 in 18,500 lbs 13,100 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
SuperCab
3.31 4x2 145.4 in 16,300 lbs 11,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 164.1 in 16,600 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 16,600 lbs 11,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 164.1 in 16,900 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 16,300 lbs 11,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 17,600 lbs 12,300 lbs Max Trailer Tow Package
3.55 4x2 164.1 in 16,600 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 164.1 in 19,400 lbs 14,000 lbs Max Trailer Tow Package
3.55 4x4 145.4 in 16,600 lbs 11,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 17,700 lbs 12,100 lbs Max Trailer Tow Package
3.55 4x4 164.1 in 16,900 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 164.1 in 19,500 lbs 13,800 lbs Max Trailer Tow Package
3.73 4x2 164.1 in 19,400 lbs 14,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 164.1 in 19,500 lbs 13,800 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
SuperCrew
3.31 4x2 145.4 in 16,500 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 157.2 in 16,700 lbs 11,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 16,800 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 157.2 in 16,800 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 16,500 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 19,400 lbs 13,900 lbs Max Trailer Tow Package
3.55 4x2 157.2 in 16,800 lbs 11,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 157.2 in 19,400 lbs 14,000 lbs Max Trailer Tow Package
3.55 4x4 145.4 in 16,900 lbs 11,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 19,400 lbs 13,800 lbs Max Trailer Tow Package
3.55 4x4 157.2 in 16,800 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 157.2 in 19,400 lbs 13,800 lbs Max Trailer Tow Package
3.73 4x2 157.2 in 19,500 lbs 14,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 145.4 in 17,100 lbs 11,000 lbs Tremor Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 157.2 in 19,500 lbs 13,700 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
Towing Capacity Chart

5th-wheel towing

Regular Cab
3.31 4x2 141.5 in 16,200 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 141.5 in 16,500 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 141.5 in 16,200 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 141.5 in 18,000 lbs 13,000 lbs Max Trailer Tow Package
3.55 4x4 141.5 in 16,500 lbs 11,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 141.5 in 18,000 lbs 11,700 lbs Max Trailer Tow Package
3.73 4x2 141.5 in 18,500 lbs 13,300 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 141.5 in 18,500 lbs 13,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
SuperCab
3.31 4x2 145.4 in 16,300 lbs 10,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 164.1 in 16,600 lbs 10,900 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 16,600 lbs 9,900 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 164.1 in 16,900 lbs 9,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 16,300 lbs 10,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 17,600 lbs 10,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 164.1 in 19,400 lbs 10,900 lbs Max Trailer Tow Package
3.55 4x2 164.1 in 16,600 lbs 10,900 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 17,700 lbs 9,900 lbs Max Trailer Tow Package
3.55 4x4 145.4 in 16,600 lbs 9,900 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 164.1 in 19,500 lbs 9,700 lbs Max Trailer Tow Package
3.55 4x4 164.1 in 16,900 lbs 9,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 19,400 lbs 13,900 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 164.1 in 19,500 lbs 13,800 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
SuperCrew
3.31 4x2 145.4 in 16,500 lbs 9,500 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 157.2 in 16,700 lbs 10,800 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 16,800 lbs 9,800 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 157.2 in 16,800 lbs 10,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 16,500 lbs 9,500 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 19,300 lbs 11,100 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Max Trailer Tow Package
3.55 4x2 157.2 in 19,400 lbs 10,800 lbs Max Trailer Tow Package
3.55 4x2 157.2 in 16,700 lbs 10,800 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 145.4 in 19,400 lbs 9,800 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Max Trailer Tow Package
3.55 4x4 145.4 in 16,800 lbs 9,800 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x4 157.2 in 19,400 lbs 10,100 lbs Max Trailer Tow Package
3.55 4x4 157.2 in 16,800 lbs 10,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 19,500 lbs 14,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 145.4 in 17,100 lbs 9,000 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Tremor Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 157.2 in 19,500 lbs 13,700 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
Engine Chart

3.5L EcoBoost V6 High Output

Ford chart label: 3.5L GTDI V6 H. O.

8,200 – 8,200 lbs

Towing Capacity Chart

Conventional towing

SuperCrew
4.10 4x4 145.4 in 14,575 lbs 8,200 lbs Available Raptor 37 Performance Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
4.10 4x4 145.4 in 14,500 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Engine Chart

3.5L PowerBoost Hybrid V6

Ford chart label: 3.5L Hybrid V6

8,300 – 12,700 lbs Engine page →

Towing Capacity Chart

Conventional towing

SuperCrew
3.55 4x2 145.4 in 16,800 lbs 11,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 145.4 in 18,500 lbs 12,700 lbs Max Trailer Tow Package
3.55 4x2 157.2 in 16,900 lbs 11,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 157.2 in 18,500 lbs 12,700 lbs Max Trailer Tow Package
3.73 4x4 145.4 in 17,100 lbs 11,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 18,400 lbs 12,300 lbs Max Trailer Tow Package
3.73 4x4 157.2 in 17,100 lbs 11,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 157.2 in 18,400 lbs 12,300 lbs Max Trailer Tow Package
Towing Capacity Chart

5th-wheel towing

SuperCrew
3.55 4x2 145.4 in 18,500 lbs 10,200 lbs Max Trailer Tow Package
3.55 4x2 145.4 in 16,800 lbs 10,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.55 4x2 157.2 in 18,500 lbs 10,400 lbs Max Trailer Tow Package
3.55 4x2 157.2 in 16,900 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 18,400 lbs 8,500 lbs Max Trailer Tow Package
3.73 4x4 145.4 in 17,100 lbs 8,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 157.2 in 18,400 lbs 8,300 lbs Max Trailer Tow Package
3.73 4x4 157.2 in 17,100 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Engine Chart

5.0L Ti-VCT V8

Ford chart label: 5.0L 4-Valve V8

8,100 – 13,000 lbs Engine page →

Towing Capacity Chart

Conventional towing

Regular Cab
3.31 4x2 122.8 in 13,100 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 141.5 in 14,800 lbs 9,900 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 122.8 in 13,200 lbs 8,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 141.5 in 14,900 lbs 9,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 122.8 in 13,900 lbs 9,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 15,300 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 18,100 lbs 13,000 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 17,900 lbs 13,000 lbs Max Trailer Tow Package
3.73 4x4 122.8 in 14,600 lbs 9,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 15,700 lbs 10,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 18,000 lbs 12,800 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 18,300 lbs 13,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
SuperCab
3.31 4x2 145.4 in 14,800 lbs 9,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 164.1 in 14,800 lbs 9,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 14,900 lbs 9,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 164.1 in 14,900 lbs 9,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,600 lbs 10,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 17,900 lbs 12,800 lbs Max Trailer Tow Package
3.73 4x2 164.1 in 15,600 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 18,200 lbs 13,000 lbs Max Trailer Tow Package
3.73 4x2 164.1 in 18,400 lbs 13,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,900 lbs 10,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 17,700 lbs 12,300 lbs Max Trailer Tow Package
3.73 4x4 164.1 in 15,900 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 164.1 in 18,500 lbs 13,000 lbs Max Trailer Tow Package
3.73 4x4 164.1 in 18,600 lbs 13,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
SuperCrew
3.31 4x2 145.4 in 14,800 lbs 9,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 157.2 in 14,800 lbs 9,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 14,800 lbs 9,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 157.2 in 14,800 lbs 9,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,700 lbs 10,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 18,100 lbs 12,900 lbs Max Trailer Tow Package
3.73 4x2 157.2 in 15,600 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 18,200 lbs 13,000 lbs Max Trailer Tow Package
3.73 4x2 157.2 in 18,500 lbs 13,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
3.73 4x4 145.4 in 15,800 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 18,400 lbs 13,000 lbs Max Trailer Tow Package
3.73 4x4 157.2 in 15,800 lbs 10,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 157.2 in 18,400 lbs 12,900 lbs Max Trailer Tow Package
3.73 4x4 157.2 in 18,700 lbs 13,000 lbs Max Trailer Tow Package + Heavy-Duty Payload Package
Towing Capacity Chart

5th-wheel towing

Regular Cab
3.31 4x2 122.8 in 13,100 lbs 8,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 141.5 in 14,800 lbs 9,800 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 122.8 in 13,200 lbs 8,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 141.5 in 14,900 lbs 9,700 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 122.8 in 13,900 lbs 9,100 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 15,300 lbs 10,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 141.5 in 17,900 lbs 12,000 lbs Max Trailer Tow Package
3.73 4x2 141.5 in 18,100 lbs 13,000 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 122.8 in 14,600 lbs 9,000 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 15,700 lbs 10,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 141.5 in 18,000 lbs 11,700 lbs Max Trailer Tow Package
3.73 4x4 141.5 in 18,300 lbs 13,000 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCab
3.31 4x2 145.4 in 14,800 lbs 9,600 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 164.1 in 14,800 lbs 9,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 14,900 lbs 9,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 164.1 in 14,900 lbs 9,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,600 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 17,900 lbs 11,100 lbs Max Trailer Tow Package
3.73 4x2 164.1 in 15,600 lbs 10,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 164.1 in 18,200 lbs 11,800 lbs Max Trailer Tow Package
3.73 4x2 164.1 in 18,400 lbs 13,000 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,900 lbs 10,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 17,700 lbs 10,700 lbs Max Trailer Tow Package
3.73 4x4 164.1 in 15,900 lbs 10,400 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 164.1 in 18,500 lbs 11,100 lbs Max Trailer Tow Package
3.73 4x4 164.1 in 18,600 lbs 12,900 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
SuperCrew
3.31 4x2 145.4 in 14,800 lbs 9,600 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x2 157.2 in 14,800 lbs 9,500 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 145.4 in 14,800 lbs 9,300 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.31 4x4 157.2 in 14,800 lbs 9,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 15,700 lbs 10,500 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 145.4 in 18,100 lbs 12,000 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Max Trailer Tow Package
3.73 4x2 157.2 in 15,600 lbs 10,300 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x2 157.2 in 18,200 lbs 11,400 lbs Max Trailer Tow Package
3.73 4x2 157.2 in 18,500 lbs 13,000 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 15,800 lbs 10,300 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 145.4 in 18,400 lbs 10,800 lbs Vehicles equipped with a 5.5 ft box will accept a 5th-wheel hitch but most 5th-wheel trailer designs are not compatible with this model + Max Trailer Tow Package
3.73 4x4 157.2 in 15,800 lbs 10,200 lbs Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
3.73 4x4 157.2 in 18,400 lbs 10,700 lbs Max Trailer Tow Package
3.73 4x4 157.2 in 18,700 lbs 12,900 lbs Heavy-Duty Payload Package + Trailer Tow Package (17T) or Trailer Tow Package (53A) or Max Trailer Tow Package
Engine Chart

F-150 Lightning

Ford chart label: Electric (F-150 Lightning)

5,000 – 10,000 lbs Engine page →

Towing Capacity Chart

Conventional towing

SuperCrew
9.61 (Fixed) 4x4 145.4 in 11,700 lbs 5,000 lbs Standard range battery
9.61 (Fixed) 4x4 145.4 in 15,000 lbs 7,700 lbs Extended range battery
9.61 (Fixed) 4x4 145.4 in 14,400 lbs 7,700 lbs Standard range battery + Trailer Tow Package
9.61 (Fixed) 4x4 145.4 in 15,900 lbs 8,500 lbs Extended range battery + Platinum model + Trailer Tow Package
9.61 (Fixed) 4x4 145.4 in 16,700 lbs 9,600 lbs Extended range battery + 20 in All-Terrain tires + Trailer Tow Package
9.61 (Fixed) 4x4 145.4 in 17,300 lbs 10,000 lbs Extended range battery + 18 in All-Terrain tires or 20 in All-Season tires + Trailer Tow Package
Technical Audit

Data sources

These citations show the Ford guide pages used to build the 2022 towing capacity chart.

Show source pages for the 2022 chart
DOC_ID: ford-tow DOCUMENT BASIS

Ford RV & Trailer Towing Guide 2022

Audit Scope PAGES: 9, 18, 21-25, 45, 50
PDF Creation Date 2022-08-08
Guide Revision Date 2022-03-07, 2022-03-22
